GeniusCore

23.8″ Intel Core i5-8260U Fan-Cooled Industrial Panel PC

$625.00

The 23.8″ Intel Core i5-8260U Fan-Cooled Industrial Panel PC powered by Intel Core i5-8260U is designed for industrial automation, factory control systems and embedded computing environments requiring long-term stability and rich I/O connectivity.

This system is delivered as a fully enclosed industrial Panel PC with aluminum alloy housing and an IP65-rated front panel, making it suitable for harsh industrial environments.

The fan-cooled Intel i5-8260U platform provides reliable performance for continuous operation, complex industrial software and multi-task control applications.

✔ Industrial-grade Intel Panel PC
✔ Rich serial & network expansion
✔ IP65 aluminum front panel design

Processor & Performance

Intel Core i5-8260U
Quad-core CPU with fan cooling
Optimized for industrial computing
Stable long-term operation

Display & Touch

23.8″ LCD Panel
Resolution: 1920 × 1080 (Full HD)
Aspect Ratio: 16:9
Capacitive Touch (Resistive Optional)

Memory & Storage

2 × DDR4 Slots (4GB–64GB)
mSATA SSD (up to 512GB)
M.2 NVMe SSD (up to 1TB)
2.5″ SATA SSD (up to 2TB)

I/O & Expansion

4 × USB 3.0, 2 × USB 2.0
HDMI Output
6 × RS232 (RS485 / RS422 Optional)
Dual Gigabit LAN

Connectivity & Power

Wi-Fi Module (Optional)
4G / 5G Module (Optional)
Wide Voltage Input: DC 9–36V

The system supports Windows by default, with Linux Ubuntu available as an option, making it suitable for a wide range of industrial software environments.

Designed for applications such as industrial HMI use cases, automation control, machine interfaces, production monitoring and factory terminals.

Specification Details
Cooling / structure Fanless
Screen size 23.8"
Aspect ratio 16:9
Resolution 1920*1080
CPU I5-8260U
Memory (RAM) SC: 2*DDR4 slot (4/8/16/32/64GB options)
Storage 1*mSATA (32/64/128/256/512GB options) 1*M.2 Nvme SSD (128/256/512GB/1TB options) 1*2.5 inch SATA SSD (128/256/512GB/1TB/2TB options)
USB SC: 4*USB3.0, 2*USB2.0
HDMI SC: 1* HDMI
Serial (COM) SC: 6*RS232 Option: 5*RS232+1*RS485 5*RS232+1*RS422 4*RS232+1*RS485+1*RS422 4*RS232+2*RS485 COM1 RS232 DB9 serial port COM2 RS232/RS485/RS422 DB9 serial port COM3 RS232/RS485 serial port on the 2*15pin phoenix connector COM4-COM6 RS232 serial port on the 2*15pin phoenix connector COM1-COM2 support 9th Pin charged
Ethernet (LAN) SC: 2*LAN
Power input DC 9~36V
Wi-Fi 1* Wifi/WIfi 6 Module option
4G / 5G 1* 4G/5G Module option
Operating system SC: Windows Linux Ubuntu option
LCD / touch SC: Capacitive Touch Option: Resistive Touch
Brightness SC: 300 cd/㎡
Operating temperature (-10-+50)
Enclosure SC: Aluminum alloy, Front panel IP65
Mounting VESA/Embedded
CPU / SoC Intel i5
Cooling Fan-cooled
