GeniusCore

12.1″ Fanless Industrial Panel PC| Intel Core i5-8260U/ i5-1135G7/ i5-1235U| XGA| IP65| PoE LAN

$561.00


12.1″ Fanless Industrial Panel PC | Intel Core i5-8260U / i5-1135G7 / i5-1235U | XGA | IP65 | PoE LAN

SKU GH-PC121-i581112-V2P

12.1″ Fanless Industrial Panel PC | Intel Core i5-8260U / i5-1135G7 / i5-1235U | XGA | IP65 | PoE LAN

The 12.1″ Fanless Intel Core i5-8260U / i5-1135G7 / i5-1235U CPU Options Industrial Panel PC  is engineered for industrial automation, HMI terminals, machine control panels, and PoE-based edge systems requiring silent operation, long-term stability, and extensive industrial I/O.

Its fanless aluminum alloy enclosure combined with an IP65-rated front panel ensures reliable operation in dusty, humid, and vibration-intensive industrial environments.

Specifications may vary by configuration. Contact us for project-specific options.

Specification Details
Cooling / structure Fanless
Screen size 12.1"
Aspect ratio 4:3
Resolution 1024*768
CPU I5-8260U
Memory (RAM) SC: 2*DDR4 slot (4/8/16/32/64GB options)
Storage 1*mSATA (32/64/128/256/512GB options) 1*M.2 Nvme SSD (128/256/512GB/1TB options) 1*2.5 inch SATA SSD (128/256/512GB/1TB/2TB options)
USB SC: 2*USB3.0, 2*USB2.0
HDMI SC: 1* HDMI
DisplayPort SC: 1* DP
Serial (COM) SC: 4*RS232 Option: 3*RS232+1*RS485 3*RS232+1*RS422 2*RS232+1*RS485+1*RS422 2*RS232+2*RS485 COM1 RS232 DB9 serial port COM2 RS232/RS485/RS422 DB9 serial port COM3 RS232/RS485 serial port on the 2*15pin phoenix connector COM4 RS232 serial port on the 2*15pin phoenix connector COM1-COM2 support 9th Pin charged
Ethernet (LAN) SC: 5*LAN, 4 ports support POE
Power input DC 9~36V
Wi-Fi 1* Wifi/WIfi 6 Module option
4G / 5G 1* 4G/5G Module option
Operating system SC: Windows Linux Ubuntu option
LCD / touch SC: Capacitive Touch Option: Resistive Touch
Brightness SC: 500 cd/㎡
Operating temperature (-10-+50)
Enclosure SC: Aluminum alloy, Front panel IP65
Mounting VESA/Embedded
CPU / SoC Intel i5
Cooling Fanless
